เลือกขนาดของเกลียว ที่ต้องการ
หมวดหมู่ : ASCO Valve ,  General Service 3-Way Valves ,
Share
Specifications
Valve Actuation
Solenoid - Direct Acting
Body Material
Brass, Stainless Steel
Media
Air, Inert Gas, Oxygen, Water, Light Oil
Pipe / Port Size
1/8 "; 1/4 "
Port Type
G ISO228/1-G BSPP
Function
3 way - 3/2 Normally Closed, 3 way - 3/2 Normally Open, 3 way - 3/2 Universal
Flow
From .04 to .2 Kv
Voltage
100 to 240 AC/DC Voltage Ranging, 12 DC, 24 DC, 48 DC | 50, 50/60, 60
Max Differential / Max Operating Pressure
10.3-34.5 Bar, 150-500 PSIG
Features
Reliable, proven compact design for long service lifetimes
Standard manual operator allows easy installation
Mountable in any position
Valves do not require a minimum operating pressure
Wide range of flow and pressure ratings are available
Quick disassembly of core tube for easy maintenance of internal parts
